Alpha Beta Pruning in AI: Adversarial Search Algorithms

Overview of Adversarial Search

Adversarial search is a problem-solving technique commonly employed in Artificial Intelligence, particularly in scenarios involving contradictory interactions (where only one party can win). Hence, it is often used in games, strategy-based systems, and negotiation AI models.

It is generally used in scenarios where one move, idea, method, or strategy of an individual or team competes with that of another individual or team to win the game or situation. The outcome of the AI is provided considering the possible moves and countermeasures of the opponent. The adversarial search algorithm is called so because the move of one individual will impact the available options for the second individual.

The adversarial search algorithm utilizes the minimax algorithm that operates on the game tree to find the most suitable move in the game environment. It uses recursion to search through the game tree and provide an optimal move considering the opponent’s optimal moves. This method is a key approach to optimizing AI decision-making in competitive environments, allowing for the selection of the best possible move.

What is Alpha Beta Pruning?

Alpha Beta Pruning in AI is an optimization technique used to enhance the efficiency of the minimax algorithm. It helps speed up the process of searching for an effective move. In a game tree, the nodes comprise all the possible moves. The existing tree parameters change as the game progresses. Alpha Beta Pruning accelerates the decision-making process by pruning branches in the game trees that are unlikely to influence the final decision, thereby saving time.

The alpha and beta refer to the additional parameters passed in the minimax function with this technique.

1. Alpha represents the best (highest) value that the maximizing player can guarantee so far.
2. Beta represents the best (lowest) value that the minimizing player can guarantee so far.

With the progress in search, if any branch becomes irrelevant compared to the current alpha or beta values, it is pruned or cut off.

Did You Know? 🔍

71% of leaders are more likely to hire a less experienced candidate with gen AI skills than a more experienced candidate without them.(Source: Microsoft)

How does Alpha Beta Pruning Work?

Alpha Beta Pruning in AI simply cuts off the irrelevant branches. Here is how it works:

Initialization of the Values: The alpha and beta values are set. Alpha is assigned negative infinity, and it is the best value for the maximizing player. Beta is assigned a value of positive infinity and is the optimal value for the minimizing player.

Evaluating the Max Node: The child of the node is the direct successor state, or the new position to which the node is moved. Now, as the max node is being evaluated, the child node is explored recursively using Minimax and Alpha Beta Pruning. The value will be updated accordingly using the formula:

Alpha = max(alpha, child’s value)

If alpha is higher than or equal to beta, prune the remaining children (beta cutoff).

Evaluating the Min Node: As the min node is evaluated, the child node is explored recursively using Minimax and Alpha Beta Pruning. The value will be updated accordingly using the formula:

Beta = min(beta, child’s value)

If beta is less than or equal to beta, prune the remaining children (using the alpha cutoff).

Difference Between Minimax Algorithm and Alpha Beta Pruning

The difference between the minimax algorithm and the Alpha Beta Pruning algorithm is as follows:

Time Complexity Analysis

Time complexity analysis provides insights into the scaling of execution time as a function of input size. Generally, the minimax algorithm without pruning has a time complexity of O(b^d), whereas with Alpha Beta Pruning, the time complexity is reduced to O(b^(d/2)).

Here, b is the branching factor or the number of possible moves, and d is the depth of the tree. According to the formula for the standard minimax algorithm, the increase in depth and branching leads to an exponential growth in the number of nodes to be evaluated. However, the pruning formula involves a reduction in time complexity.

Alpha Beta Pruning Implementation in Python

Here is the Python implementation of the Alpha Beta Pruning technique in a two-player game:

def minimax(node, depth, alpha, beta, maximizingPlayer):
if depth == 0 or is_terminal(node):
return evaluate(node)if maximizingPlayer:
maxEval = float('-inf')
for child in get_children(node):
eval = minimax(child, depth - 1, alpha, beta, False)
maxEval = max(maxEval, eval)
alpha = max(alpha, eval)
if beta <= alpha:  # Beta cutoff
break
return maxEval
else:
minEval = float('inf')
for child in get_children(node):
eval = minimax(child, depth - 1, alpha, beta, True)
minEval = min(minEval, eval)
beta = min(beta, eval)
if beta <= alpha:  # Alpha cutoff
break
return minEval

Parts of the Code

• Node: It refers to the current game state
• Depth: It is the depth limit of the search (cutoff to avoid infinite recursion)
• Alpha: Best value maximizer can guarantee so far
• Beta: Best value minimizer can guarantee so far
• maximizingPlayer: Boolean, True if it's the maximizer’s turn
• is_terminal(node): Checks if the node is a terminal state
• evaluate(node): Assigns a score to a node (static evaluation)
• get_children(node): Returns all possible following states from the current node

Optimize Minimax Search Using Alpha Beta Pruning

Here is how the Alpha Beta Pruning algorithm in AI can optimize the minimax search algorithm:

Advanced Optimizations

Optimizing Alpha Beta Pruning in AI can further contribute to enhancing the search process. Here is how it goes:

• Heuristic search: Employing heuristics to direct the search towards promising areas of the search tree
• Move ordering: Prioritizing the modes depending on the probability of their quality
• Iterative deepening: Slowly going deeper into the search tree until a time limit is reached
• Transposition tables: Recording the previously explored positions to avoid redundancy in calculations

Pseudocode and Explanation

Here is the Alpha Beta Pruning example pseudocode, provided for better clarity, along with an accompanying explanation. Let’s understand:

function AlphaBeta(node, depth, maximizing, alpha, beta):
if isTerminal(node) or depth == maxDepth:
return getScore(node)
if maximizing:
currentMax = -∞
for successor in generateMoves(node):
score = AlphaBeta(successor, depth + 1, false, alpha, beta)
currentMax = max(currentMax, score)
alpha = max(alpha, currentMax)
if alpha >= beta:
break   // Beta Cutoff
return currentMax
else:

The Alpha Beta Pruning in AI example code will be processed as follows:

• Start at the root node with depth 0, assuming it’s the maximizing player’s turn
• Check the base condition and return the score if the node is terminal or the maximum depth is reached
• Maximizing
• Initialize currentMax = negative infinity
• Loop over each possible move
• Recursively call AlphaBeta for each move, minimizing turns
• Prune if alpha is greater than or equal to beta
• Return the best score found
• Minimizing
• Same logic but with currentMin = positive infinity
• Update Beta
• Prune if beta is less than or equal to alpha
• Recursion occurs, and the optimal value goes up to the root
• Give the best achievable score for the maximizing player

Join our 4.5 ⭐ rated program, trusted by over 2,000 learners who have successfully launched their careers as GenAI professionals. Start your learning journey with us today! 🎯

Alpha Beta Pruning Examples

Let’s depict the Alpha Beta Pruning example for clear understanding:

Scenario: The root node is max, the branching factor is two, the tree depth is three, and the left node values are 8,12,6,14,5,9,3,7. Now, stepwise Alpha Beta Pruning will go as follows:

Step 1: Start at the root (max node). Alpha will be negative infinity, and beta will be positive infinity

Step 2: First Child of Root - Min Node

Step 2.1: First Child of Min Node - Max Node

• Explore First Leaf (value = 8) and return 8
• Explore Second Left (value = 12) and return 12
• Max Node picks max(8,12) = 12
• Min Node updates Beta = 12

Step 2.2: Second Child of Min Node - Max Node

• Explore First Leaf (value = 6) and return 6
• Explore Second Left (value = 14) and return 14
• Max Node picks max(6,14) = 14
• Min Node picks min(12,14) = 12

Step 3: Max Node at Root updates Alpha = 12

Step 4: Second Child of Root - Min Node

Alpha = 12 and beta = positive infinity

Step 4.1: First Child of Min Node - Max Node

• Explore First Leaf (value = 5) and return 5
• Explore Second Left (value = 9) and return 9
• Max Node picks max(5,9) = 9
• Min Node updates Beta = 9

Step 5: Alpha (12) ≥ Beta (9)

Prune to cut off unnecessary search

Step 6: Final Decision

Root Max Node picks max(12,9) = 12

Applications of Alpha Beta Pruning

The Alpha Beta Pruning algorithm in AI finds application in various fields such as:

• Games: It is used in games like Chess, Checkers, and Othello, where it contributes to increased efficiency, better moves of the AI, and strengthens the strategies.
• Real-time decision-making: It finds applications in autonomous devices to provide the most appropriate results based on the available options. Specifically, Alpha Beta Pruning can be used in map systems, task execution-based applications, and other similar applications.
• Prediction and forecasting: It also involves evaluating existing parameters and predicting possibilities based on them. It includes financial and weather forecasting, supply chain management, portfolio optimization, market analysis, and other such scenarios.
• Strategic decision-making: The working mechanism of Alpha Beta Pruning is also ideal for simulating scenarios. It involves use in the military, companies, and government planning for strategy development, identifying possible opponent actions, and other applications.

Advantages of Alpha Beta Pruning

Alpha Beta Pruning is an effective technique that can be used to gain the following advantages:

• Quick results: The technique reduces computation time by pruning branches of lesser significance. It helps pace up the decision-making.
• Same optimal result: Despite pruning, the technique does not compromise the quality of the result.
• Deeper search: The technique facilitates a more thorough exploration of the game tree without requiring additional time, thereby enhancing efficiency. It also improves the scalability of the apps and demonstrates applicability in complex scenarios.

Challenges in Alpha Beta Pruning

Alpha Beta Pruning in AI, however, presents specific challenges as well. Here are the insights into the same:

• The technique heavily relies on move ordering. Evaluating the most decisive move first enhances the algorithm's efficiency by allowing the pruning of more branches. Hence, computation time is reduced. If weak moves are evaluated first, the time required will be longer.
• The suitability of Alpha Beta Pruning is limited to 2-player games. It can't be used in dice games.
• The deep searches and complex situations lead to a considerable growth of game trees, affecting the management.
• High branching and non-optimal play also have a negative impact on pruning.

Not confident about your AI skills? Join the Artificial Intelligence Engineer Program and master generative AI, prompt engineering, python programming, reinforcement learning and NLP in just 11 months! 🎯

Conclusion

The combination of the minimax algorithm with Alpha Beta Pruning enhances the efficiency of AI in various areas. From gaming to decision-making, forecasting, and simulation, these applications are highly beneficial for real-life scenarios. Alpha Beta Pruning enhances the efficiency of AI models by pruning the non-significant branches of the game tree.

The pruning also contributes to the scalability and complexity of the AI. Furthermore, the pruning yields the same results as the minimal algorithm without compromising quality. Hence, Alpha Beta Pruning is a practical approach to building smart, fast, and highly efficient systems.

Advance Your Career in AI and ML with Simplilearn

AI and ML are revolutionizing the world by enabling the quick, easy, and efficient completion of tasks, while also contributing to informed decision-making. With further work being done to improve their efficiency, gaining proficiency in the field holds promising results. Conceptual clarity, hands-on experience, and guidance from experts are the building blocks of a career in the field. All of these are provided right here at Simplilearn with the following courses.

Applied Generative AI Specialization

• Offered in collaboration with Purdue University
• Learn from live masterclasses and Purdue University staff
• Access to learn popular GenAI tools
• Gain practical experience in building generative AI and agentic AI apps with over seven industry-relevant projects
• Get access to Purdue’s prestigious alumni network

Artificial Intelligence Engineer

• Offered in collaboration with IBM
• Covers ML, Deep Learning, GenAI, NLP, and other associated concepts
• Access to the capstone and over 25 industry-relevant AI projects
• Includes live sessions on the latest AI trends, prompt engineering, generative AI tools, and much more
• Features AMA sessions with IBM leaders

FAQs

1. Why is alpha‑beta pruning important in AI?

The Alpha Beta Pruning technique enhances the efficiency of the minimax algorithm. It reduces the time required to find the best move by pruning the unnecessary branches. It provides results with uncompromised quality in less time.

2. When does alpha‑beta pruning perform worst?

The worst performance of Alpha Beta Pruning is witnessed when the best moves aren’t encountered first. Since the best moves are now present, the AI must examine all branches, taking the same amount of time as the standard minimax algorithm.

3. How does move ordering affect pruning efficiency?

If the best moves are present first, more pruning will occur, whereas in the scenario of poor moves being placed first, there will be less pruning. In case of less pruning, the AI will have to explore all the branches, thus exhibiting poor time efficiency.

4. What is principal variation search?

Principal variation search is a search refining method that helps find the best move through shallow search. This move is further explored in more depth. It adds to the efficiency of Alpha Beta Pruning.

5. What is iterative deepening?

Iterative deepening in adversarial search algorithms involves exploring the game tree to a limited depth, followed by increasing the depth by one level with each iteration. It also improves the move ordering, thus enhancing the efficiency of the technique.

6. Can caching (memoization) improve performance?

Yes, caching or memoization does have a positive influence on performance improvement. It does so by reducing the requirement for redundant computations, thus saving time. Caching also contributes to increased efficiency.

7. Can alpha–beta pruning be parallelized for faster computation in large search spaces?

Yes, parallelization of Alpha Beta Pruning is possible. It requires careful consideration and the use of advanced techniques for implementation.
