MATLAB, a programming language for technical computing, is a powerful tool that can perform all sorts of math tasks in an engineering or scientific environment. It's incredibly flexible, with an extensive array of functions that you can use to meet specific needs in your environment.
Using such a complex environment can prove daunting at first, but this Cheat Sheet can help: Learn common MATLAB commands; become familiar with standard operators and precedence and learn to recognize line plot styles.
Matlab Basics
Workspace
ans %Most recent answer
clc %clear command window
clear var %clear variables Workspace
clf %Clear all plots
close all %Close all plots
ctrl-c %Kill the current calculation
doc fun %open documentation
disp(’text’) %Print text
format short—long %Set output display format
help fun %open in-line help
load filename {vars} %load variables from .mat file
save {-append} file {vars} %save var to file
addpath path %include path to ..
iskeyword arg %Check if arg is keyword % This is a comment Comments
... %connect lines (with break)
";" (after command) %suppresses output
scriptname %runs scriptname.m
tic, toc %start and stop timer
ver %List of installed toolboxes
Defining and Changing Variables
myVariable = 4 % Notice Workspace pane shows newly created variable
myVariable = 4; % Semi colon suppresses output to the Command Window
4 + 6 % ans = 10
8 * myVariable % ans = 32
2 ^ 3 % ans = 8
a = 2; b = 3;
c = exp(a)*sin(pi/2) % c = 7.3891
% Logicals
1 > 5 % ans = 0
10 >= 10 % ans = 1
3 ~= 4 % Not equal to -> ans = 1
3 == 3 % equal to -> ans = 1
3 > 1 && 4 > 1 % AND -> ans = 1
3 > 1 || 4 > 1 % OR -> ans = 1
~1 % NOT -> ans = 0
% Logicals can be applied to matrices:
A > 5
% for each element, if condition is true, that element is 1 in returned matrix
A( A > 5 )
% returns a vector containing the elements in A for which condition is true
% Strings
a = 'MyString'
length(a) % ans = 8
a(2) % ans = y
[a,a] % ans = MyStringMyString
% Cells
a = {'one', 'two', 'three'}
a(1) % ans = 'one' - returns a cell
char(a(1)) % ans = one - returns a string
% Structures
A.b = {'one','two'};
A.c = [1 2];
A.d.e = false;
% Variables can be saved to .mat files
save('myFileName.mat') % Save the variables in your Workspace
load('myFileName.mat') % Load saved variables into Workspace
Arithmetics
transpose(A) % Transpose the matrix, which is the same as:
A one
A' % Concise version of complex transpose
A.' % Concise version of transpose (without taking complex conjugate)
size(A) % ans = 3 3
% Element by Element Arithmetic vs. Matrix Arithmetic
% On their own, the arithmetic operators act on whole matrices. When preceded
% by a period, they act on each element instead. For example:
A * B % Matrix multiplication
A .* B % Multiple each element in A by its corresponding element in B
% There are several pairs of functions, where one acts on each element, and
% the other (whose name ends in m) acts on the whole matrix.
exp(A) % exponentiate each element
expm(A) % calculate the matrix exponential
sqrt(A) % take the square root of each element
sqrtm(A) % find the matrix whose square is A
% Solving matrix equations (if no solution, returns a least squares solution)
% The \ and / operators are equivalent to the functions mldivide and mrdivide
x=A\b % Solves Ax=b. Faster and more numerically accurate than using inv(A)*b.
x=b/A % Solves xA=b
inv(A) % calculate the inverse matrix
pinv(A) % calculate the pseudo-inverse
% Common matrix functions
zeros(m,n) % m x n matrix of 0's
ones(m,n) % m x n matrix of 1's
diag(A) % Extracts the diagonal elements of a matrix A
diag(x) % Construct a matrix with diagonal elements listed in x, and zeroes elsewhere
eye(m,n) % Identity matrix
linspace(x1, x2, n) % Return n equally spaced points, with min x1 and max x2
inv(A) % Inverse of matrix A
det(A) % Determinant of A
eig(A) % Eigenvalues and eigenvectors of A
trace(A) % Trace of matrix - equivalent to sum(diag(A))
isempty(A) % Tests if array is empty
all(A) % Tests if all elements are nonzero or true
any(A) % Tests if any elements are nonzero or true
isequal(A, B) % Tests equality of two arrays
numel(A) % Number of elements in matrix
triu(x) % Returns the upper triangular part of x
tril(x) % Returns the lower triangular part of x
cross(A,B) % Returns the cross product of the vectors A and B
dot(A,B) % Returns scalar product of two vectors (must have the same length)
transpose(A) % Returns the transpose of A
fliplr(A) % Flip matrix left to right
flipud(A) % Flip matrix up to down
% Matrix Factorisations
[L, U, P] = lu(A) % LU decomposition: PA = LU,L is lower triangular, U is upper triangular, P is permutation matrix
[P, D] = eig(A) % eigen-decomposition: AP = PD, P's columns are eigenvectors and D's diagonals are eigenvalues
[U,S,V] = svd(X) % SVD: XV = US, U and V are unitary matrices, S has non-negative diagonal elements in decreasing order
[Q, R] = qr(A) % if A is mxn, Q is mxm and R is mxn upper triangular
% Common vector functions
max % largest component
min % smallest component
length % length of a vector
sort % sort in ascending order
sum % sum of elements
prod % product of elements
mode % modal value
median % median value
mean % mean value
std % standard deviation
perms(x) % list all permutations of elements of x
find(x) % Finds all non-zero elements of x and returns their indexes, can use comparison operators,
% i.e. find( x == 3 ) returns indexes of elements that are equal to 3
% i.e. find( x >= 3 ) returns indexes of elements greater than or equal to 3
Elementary Functions
sin(x)
cos(x)
tan(x)
asin(x)
acos(x)
atan(x)
exp(x)
sqrt(x)
log(x)
log10(x)
abs(x) %If x is complex, returns magnitude
min(x)
max(x)
ceil(x)
floor(x)
round(x)
rem(x)
rand % Uniformly distributed pseudorandom numbers
randi % Uniformly distributed pseudorandom integers
randn % Normally distributed pseudorandom numbers
%Complex math operations
abs(x) % Magnitude of complex variable x
phase(x) % Phase (or angle) of complex variable x
real(x) % Returns the real part of x (i.e returns a if x = a +jb)
imag(x) % Returns the imaginary part of x (i.e returns b if x = a+jb)
conj(x) % Returns the complex conjugate
% Common constants
pi
NaN
inf
% Given a meshgrid X,Y and a function defined on the meshgrid like Gauss, interpolates the value of the function at the point u1,u2
interp2(X,Y,Gauss,u1,u2)
Complex Numbers
abs(z) %Absolute value and complex magnitude
angle(z) %Phase angle
complex(a,b) %Create complex numbers
conj(z) %Elementwise complex conjugate i or j Imaginary unit
imag(z) %Imaginary part of complex number
isreal(z) %Determine whether array is real
real(z) %Real part of complex number
ctranspose(Z) %Complex conjugate transpose
Constants
pi %π = 3.141592653589793
NaN %Not a number (i.e. 0/0)
Inf %Infinity
eps %Floating-point relative accuracy
realmax %Largest positive floating-point number
realmin %Smallest positive floating-point number
Keyboard Shortcuts
Numbers and Linear Algebra
A’ %Transpose of matrix or vector
inv(A) %inverse of A (use with care!)
det(A) %determinant of A
eig(A),eigs(A) %eigenvalues of A (subset)
cross(A,B) %Cross product
dot(A,B) %Dot product
kron(A,B) %Kronecker tensor product
norm(x) %Vector and matrix norms
linsolve(A,B) %Solve linear system of equations
rank(A) %Rank of matrix
trace(A) %Sum of diagonal elements
curl(X,Y,Z,U,V,W) %Curl and angular velocity
divergence(X,..,W) %Compute divergence of vector field
null(A) %Null space of matrix
orth(A) %Orthonormal basis for matrix range
mldivide(A,B) %Solve linear system Ax = B for x
mrdivide(B,A) %Solve linear system xA = B for x
decomposition(A) %Matrix decomposition
lsqminnorm(A,B) %Least-squares solution to linear eq.
rref(A) %Reduced row echelon form
balance(A) %Diagonal scaling (improve eig. vec.)
svd(A) %Singular value decomposition
gsvd(A,B) %Generalized svd
chol(A) %Cholesky factorization
Numerical Integration and Differentiation
integral(f,a,b) %Numerical integration
integral2(f,a,b,c,d) %2D num. integration
integral3(f,a,b,..,r,s) %3D num. integration
trapz(x,y) %Trapezoidal integration
cumtrapz(x,y) %Cumulative trapez integration
diff(X) %Differences (along columns)
gradient(X) %Numerical gradient
Matrix Functions/ Linear Algebra
zeros(m,n) % m x n matrix of 0's
ones(m,n) % m x n matrix of 1's
diag(A) % Extracts the diagonal elements of a matrix A
diag(x) % Construct a matrix with diagonal elements listed in x, and zeroes elsewhere
eye(m,n) % Identity matrix
linspace(x1, x2, n) % Return n equally spaced points, with min x1 and max x2
inv(A) % Inverse of matrix A
det(A) % Determinant of A
eig(A) % Eigenvalues and eigenvectors of A
trace(A) % Trace of matrix - equivalent to sum(diag(A))
isempty(A) % Tests if array is empty
all(A) % Tests if all elements are nonzero or true
any(A) % Tests if any elements are nonzero or true
isequal(A, B) % Tests equality of two arrays
numel(A) % Number of elements in matrix
triu(x) % Returns the upper triangular part of x
tril(x) % Returns the lower triangular part of x
cross(A,B) % Returns the cross product of the vectors A and B
dot(A,B) % Returns scalar product of two vectors (must have the same length)
transpose(A) % Returns the transpose of A
fliplr(A) % Flip matrix left to right
flipud(A) % Flip matrix up to down
Matrix Manipulation
A(2:3,2:3) % Creates a new matrix from the old one
%ans =
% 5 42
% 8 9
A(:,1) % All rows in column 1
%ans =
% 1
% 4
% 7
A(1,:) % All columns in row 1
%ans =
% 1 2 3
[A ; A] % Concatenation of matrices (vertically)
%ans =
% 1 2 3
% 4 5 42
% 7 8 9
% 1 2 3
% 4 5 42
% 7 8 9
% this is the same as
vertcat(A,A);
[A , A] % Concatenation of matrices (horizontally)
%ans =
% 1 2 3 1 2 3
% 4 5 42 4 5 42
% 7 8 9 7 8 9
% this is the same as
horzcat(A,A);
A(:, [3 1 2]) % Rearrange the columns of original matrix
%ans =
% 3 1 2
% 42 4 5
% 9 7 8
A(1, :) =[] % Delete the first row of the matrix
A(:, 1) =[] % Delete the first column of the matrix
squeeze(A); % Removes singular dimensions ie. 2x1x3 -> 2x3
Graphics
Plotting
x = 0:.10:2*pi; % Creates a vector that starts at 0 and ends at 2*pi with increments of .1
y = sin(x);
plot(x,y)
xlabel('x axis')
ylabel('y axis')
title('Plot of y = sin(x)')
axis([0 2*pi -1 1]) % x range from 0 to 2*pi, y range from -1 to 1
plot(x,y1,'-',x,y2,'--',x,y3,':') % For multiple functions on one plot
legend('Line 1 label', 'Line 2 label') % Label curves with a legend
% Alternative method to plot multiple functions in one plot.
% while 'hold' is on, commands add to existing graph rather than replacing it
plot(x, y)
hold on
plot(x, z)
hold off
loglog(x, y) % A log-log plot
semilogx(x, y) % A plot with logarithmic x-axis
semilogy(x, y) % A plot with logarithmic y-axis
fplot (@(x) x^2, [2,5]) % plot the function x^2 from x=2 to x=5
% Creates a meshgrid (2D grid) to calculate a function for every point in the grid
[X, Y] = meshgrid(x_min:step:x_max, y_min:step:y_max)
grid on % Show grid; turn off with 'grid off'
axis square % Makes the current axes region square
axis equal % Set aspect ratio so data units are the same in every direction
scatter(x, y); % Scatter-plot
hist(x); % Histogram
stem(x); % Plot values as stems, useful for displaying discrete data
bar(x); % Plot bar graph
z = sin(x);
plot3(x,y,z); % 3D line plot
pcolor(A) % Heat-map of matrix: plot as grid of rectangles, coloured by value
contour(A) % Contour plot of matrix
contourf(A) % Filled contour plot of matrix
mesh(A) % Plot as a mesh surface
h = figure % Create new figure object, with handle h
figure(h) % Makes the figure corresponding to handle h the current figure
close(h) % close figure with handle h
close all % close all open figure windows
close % close current figure window
shg % bring an existing graphics window forward, or create new one if needed
clf clear % clear current figure window, and reset most figure properties
% Properties can be set and changed through a figure handle.
% You can save a handle to a figure when you create it.
% The function get returns a handle to the current figure
h = plot(x, y); % you can save a handle to a figure when you create it
set(h, 'Color', 'r')
% 'y' yellow; 'm' magenta, 'c' cyan, 'r' red, 'g' green, 'b' blue, 'w' white, 'k' black
set(h, 'LineStyle', '--')
% '--' is solid line, '---' dashed, ':' dotted, '-.' dash-dot, 'none' is no line
get(h, 'LineStyle')
% The function gca returns a handle to the axes for the current figure
set(gca, 'XDir', 'reverse'); % reverse the direction of the x-axis
% To create a figure that contains several axes in tiled positions, use subplot
subplot(2,3,1); % select the first position in a 2-by-3 grid of subplots
plot(x1); title('First Plot') % plot something in this position
subplot(2,3,2); % select second position in the grid
plot(x2); title('Second Plot') % plot something there
% Given
x1 = [-3:0.5:3];
x2 = x1;
y = randi(500, length(x1), length(x1));
% Show a 3-D plot
figure
subplot(2,1,1);
surf(x1,x2,y);
xlabel(’x_1’);
ylabel(’x_2’);
% Show contours
subplot(2,1,2);
contour(x1,x2,y);
xlabel(’x_{1}’);
ylabel(’x_{2}’);
axis equal
% Show a colour map
figure
imagesc(x1,x2,y)
xlabel(’x_{1}’);
ylabel(’x_{2}’);
Plot Types
- Plot
- Plot3
- Stairs
- Errorbar
- Stackedplot
- Loglog
- Semilogs
- Semilogy
- Polarplot
- Contour
- Quiver
- Quiver3
- Histogram
- Pie
- Scatter
- Scatterhist
- Plotmatrix
- Heatmap
Programming Methods
Functions
load('myFile.mat', 'y')
% Command syntax:
load myFile.mat y % no parentheses, and spaces instead of commas
% Calling a function from a script
% [arguments out] = function_name(arguments in)
[V,D] = eig(A);
[~,D] = eig(A); % if you only want D and not V
% To use functions or scripts, they must be on your path or current directory
path % displays current path
addpath /path/to/dir % add to path
rmpath /path/to/dir % remove from path
cd /path/to/move/into % change directory
% M-file Scripts
% Have .m extensions
% M-file Functions
% 'help double_input.m' returns the comments under line beginning function
function output = double_input(x)
%double_input(x) returns twice the value of x
output = 2*x;
end
double_input(6) % ans = 12
% Example that returns the square of it's input, assigned to the handle sqr:
sqr = @(x) x.^2;
sqr(10) % ans = 100
doc function_handle % find out more
Anonymous Functions
% defined via function handles
f = @(x) cos(x.ˆ2)./(3*x);
Relational and Logical Operations
== %Check equality
∼= %Check inequality
> %greater than
>= %greater or equal to
< %less than
<= %less or equal to
&, && %logical AND
∼ %logical NOT
|, | | %logical OR
xor %logical exclusive-OR
if, elseif Conditions
if (a > 15)
disp('Greater than 15')
elseif (a == 23)
disp('a is 23')
else
disp('neither condition met')
end
Switch Case
n = input('Enter a number: ');
switch n
case -1
disp('negative one')
case 0
disp('zero')
case {1,2,3} %check three cases together
disp('positive one')
otherwise
disp('other value')
end % control structures terminate with end
For-Loop
for k = 1:5
disp(k)
end
While-Loop
k = 0;
while (k < 5)
k = k + 1;
end
Special Topics
Polynomials
poly(x) %Polynomial with roots x
poly(A) %Characteristic polynomial of matrix
polyeig(x) %Polynomial eigenvalue problem
polyfit(x,y,d) %Polynomial curve fitting
residue(b,a) %Partial fraction expansion/decomposition
roots(x) %Polynomial roots
polyval(p,x) %Evaluate poly p at points x
conv(u,v) %Convolution and polynomial multiplication
deconv(u,v) %Deconvolution and polynomial division
polyint(p,k) %Polynomial integration
polyder(p) %Polynomial differentiation
Interpolation and Fitting
interp1(x,v,xq) %1-D data interpolation (table lookup)
interp2(X,Y,V,Xq,Yq) %2D interpolation for meshgrid data
interp3(X,..V,..Zq) %3D interpolation for meshgrid data
pchip(x,v,xq) %Piece. cubic Hermite poly interpol
spline(x,v,xq) %Cubic spline data interpolation
ppval(pp,xq) %Evaluate piecewise polynomial
mkpp(breaks,coeffs) %Make piecewise polynomial
unmkpp(pp) %Extract piecewise polynomial details
Differential Equations
ode45(ode,tspan,y0) %Solve system of nonstiff ODE
ode15s(ode,tspan,y0) %Solve system of stiff ODE
pdepe(m,pde,ic,bc,xm,ts) %Solve 1D PDEs
pdeval(m,xmesh,usol,xq) %Interpolate num. PDE solution
Optimization
fminbnd(fun,x1,x2) %Find minimum of fun(x) in [x1, x2]
fminsearch(fun,x0) %Find minimum of function
lsqnonneg(C,d) %Solve non-neg. lin. least-squares prob.
fzero(fun,x0) %Root of nonlinear function
optimget(opt,’par’) %Optimization options values
optimset(’opt’,val) %Define optimization options
Descriptive Statistics
bounds(A) %Smallest and largest elements
max(A) %Maximum elements of an array
min(A) %Minimum elements of an array
mode(A) %Most frequent values in array
mean(A) %Average or mean value of array
median(A) %Median value of array
std(A) %Standard deviation
var(A) %Variance
hist(X) %calculate and plot histogram
corrcoef(A) %Correlation coefficients
cov(A) %Covariance
xcorr(x,y) %Cross-correlation
xcov(x,y) %Cross-covariance
rand %Uniformly distributed random numbers
randn %Normally distributed random numbers
randi %Uniformly distributed pseudorandom integers
Discrete Math
factor(n) %Prime factors
factorial(n) %Factorial of input
gcd(n,m) %Greatest common divisor
lcm(n,m) %least common multiple
mod(a,m) %Remainder after division (modulo operation)
ceil(X) %Round toward positive infinity
fix(X) %Round toward zero
floor(X) %Round toward negative infinity
round(X) %Round to nearest decimal or integer
MATLAB as a Programming Language
MATLAB is a high-level language and interactive environment for numerical computation, visualization, and programming. MATLAB supports the entire range of engineering and science applications, including control, signal processing, communications, data analysis, optimization, and system modeling.
A single toolbox handles virtually all computational tasks in engineering and scientific research.
Learn over a dozen of data science tools and skills with Professional Certificate Program in Data Science and get access to masterclasses by Purdue faculty. Enroll now and add a shining star to your data science resume!
Conclusion
Learning MATLAB will help you become a data scientist. Data science is one of the most lucrative fields to enter today. And it's only going to get bigger.
In order to be successful in this industry, you need to know MATLAB and other programming languages like Python and R. You'll also need some practical experience applying data science techniques to solve real-world problems.
Simplilearn's Professional Certificate Program in Data Science will help you master MATLAB and other programming languages like Python and R. You'll also learn how to apply data science techniques to solve real-world problems.
The course covers various topics in depth and has a lot of practical components for getting you job-ready from day one.
