Docker is an innovative technology that developed in a short period (about two years) and is in great demand in modern IT industries today.

Docker Raspberry Pi is a tool for developing, deploying and executing applications using containers. It is lightweight and most effective as compared to virtual machines. In this article, we will understand how this Raspberry Pi technology is different and innovative in terms of other competitive technologies.

PRINCE2® Certification Exam Made Easy to Crack

PRINCE2® Foundation & Practitioner CertificationExplore Course
PRINCE2® Certification Exam Made Easy to Crack

Installing Docker Raspberry Pi

For installing Docker using Raspberry Pi, we need to follow the below steps.

  • Keep your system upgraded and updated.
  • Install the package and download the installation script.
  • Give access to a non-root developer to perform Docker commands.
  • Confirm the installation and check the Docker version. It should be updated.
  • Check the Setup and Test by executing a “hello-world” using the container.

Let us now understand these steps in detail.

Step 1:

Upgrade and Update

In this step, keep upgrading and updating your system and install the most advanced software version.

Run this command "sudo apt-get update && sudo apt-get upgrade" as shown in the below screenshot.

Raspberry_Pi_Docker_1

Step 2:

Download the right script and install Docker on the Raspberry Pi environment.

Push this below installation script.

curl -fsSL https://get.docker.com -o get-docker.sh

Run the script with the help of the below command:

sudo sh get-docker.sh

This establishes the expected packages on the Raspbian Linux administration environment.

/Raspberry_Pi_Docker_2

Here is the running output of the Docker version as per the above command.

Raspberry_Pi_Docker_3

Earn 40% More Than Non-Certified Peers

Lean Six Sigma Expert Masters ProgramEnroll Now!
Earn 40% More Than Non-Certified Peers

Step 3:

Append a non-root user on the Docker group

As per the Raspberry Pi process, whichever user has the administrative rights whom we can consider as root user can execute containers. For example, if a case user is not logged in to the admin root, then they should use the sudo prefix.

We can also add the non-root users to the Docker group, which will enable running the executed docker commands.

Here is the syntax for adding users to the Docker group:

sudo usermod -aG docker [user_name]

We can consider it the default user for adding the Pi user in Raspbian.

Refer to the below command:

 sudo usermod -aG docker Pi

We need to log out of the system to check the output process.

Step 4:

For checking the Updated Docker Version and info details on your Raspberry Pi, refer to the below command.

docker version

The below output screenshot will show the docker version with all the relevant details.

For getting the system-wide details, which involve the list of containers, kernel version, and docker images, run this below command.

docker info

Step 5:

Execute/run the sample Hello World Container. Here we need to configure and set up this below command.

docker run hello-world

After running the above command, it will contact the Docker daemon and pull the “hello-world” image.

The output will show the “installation appears to be working correctly” message.

Raspberry_Pi_Docker_4.

Docker Raspberry Pi 4

  • Raspberry Pi 4 can work as a low-cost Docker resolution for application development and various responsibilities. It has the latest 8GB version.
  • A Raspberry Pi 4 is a single-board processor. To connect Docker on your Raspberry Pi 4, we need the following:
  • A Raspberry Pi 4 Type-C power accumulation.
  • A microSD card has a minimum of 32GB storage space, including the Raspberry Pi OS image on it.
  • Internet connectivity using the Raspberry Pi 4.
  • A laptop or computer for VNC remote desktop accessibility using SSH way to the Raspberry Pi 4.

Earn the Most Coveted DevOps Certification!

DevOps Engineer Masters ProgramExplore Program
Earn the Most Coveted DevOps Certification!

Installing Docker Raspberry Pi 4

Below is the command for updating Raspberry Pi OS.

$ sudo apt update

Raspberry_Pi_Docker_5.

After running the command, it will show the below output.

Raspberry_Pi_Docker_6

Run the below command to update all the Raspberry Pi OS environment packages.

 $ sudo apt upgrade

Output:

Raspberry_Pi_Docker_7

Raspberry_Pi_Docker_8.

Raspberry Pi 4 Docker

Raspberry Pi 4 can be applied to build a private cloud resolution with Ansible and Docker, which are great tools used by various large-scale cloud systems that automate the tasks, configure them, and enable containerization for the applications.

After booting your system, the following commands can implement the most advanced Rasbian updates.

$ sudo apt update

$ sudo apt dist-upgrade

To define the hostname, we need to add two files as per the below command.

$ sudo nano /etc/hostname

$ sudo nano /etc/hosts

Choose The Right DevOps Program

This table compares various DevOps programs offered by Simplilearn, based on several key features and details. The table provides an overview of the courses' duration, skills you will learn, additional benefits, among other important factors, to help you make an informed decision about which course best suits your needs.

Program Name DevOps Engineer Masters Program Post Graduate Program in DevOps
Geo All All
University Simplilearn Caltech
Course Duration 11 Months 9 Months
Coding Experience Required Basic Knowledge Basic Knowledge
Skills You Will Learn 40+ Skills Including Ansible, Puppet, Chef, Jenkins, etc. 10+ Skills Including CI,CD, DevOps on Cloud, Deployment Automation, etc.
Additional Benefits Masters Certification
Real Life Projects
Learn 40+ Skills and Tools
Caltech Campus Connect
Career Services
Masterclasses by Caltech Instructors
Cost $$ $$$
Explore Program Explore Program

Conclusion

We hope this article helped you understand Raspberry Pi Docker. In this article, we discussed the concept of various repositories and their different types, along with examples that will be helpful to professional developers from Java and .net backgrounds, application architectures, cloud specialists, and other learners, and testers looking for various uses of Raspberry Pi  Docker with the containers.

Besides pursuing varied courses provided by Simplilearn, you can also sign up on our SkillUp platform. This platform, a Simplilearn initiative, offers numerous free online courses to help with the basics of multiple programming languages, including cloud docker hub. You can also opt for our Post Graduate Program in DevOps to improve your career prospects.

If you have any questions, feel free to post them in the comments below. Our team will get back to you at the earliest.
