Regression is a statistical technique used to model the relationship between a dependent variable and one or more independent variables. The dependent variable is the response variable, and the independent variables are the predictor variables. Regression is a powerful tool that can be used to understand the relationships between variables, make predictions, and test hypotheses.

This blog post aims to introduce the reader to the basics of regression in Matlab. We will begin by discussing the different types of regression, and then we will show how to perform a regression analysis in Matlab.

Become a Data Scientist With Real-World Experience

Data Scientist Master’s ProgramExplore Program
Become a Data Scientist With Real-World Experience

Introduction to Matlab Regression

MATLAB Regression is a function used to find the linear relationship between two or more variables. One variable is regarded as an explanatory variable, while the second variable is viewed as the dependent variable. It is a continuous variable in its nature. The dependent variable is a term used to describe variables whose values are analyzed or focused, while the independent or explanatory variable concentrates on the dependent variable. In the case of dependent variables, it is referred to as Y, while the explanatory or independent variables are referred to as X. To perform a multi-linear regression analysis of the response in the matrix of the explanatory variables on the predictors of the matrix of the independent variable, the Matlab Regression function is employed.

This can be used to find the line of best fit for scattered data. The data does not have to be perfectly linear, but it should be close. Using this method, one can also figure out the equation of the line of best fit. Matlab regression is a method of fitting a curve to data points so that the curve can be used to predict future values. Matlab regression is a powerful tool that can be used to find trends in data sets that would otherwise be difficult to detect.

Syntax Of Matlab Regression: b = regress(y,X)

How Does Regression Work in Matlab?

Regression analysis examines a relationship between two variables. In Matlab, a regression can be performed using the built-in regress function. This function takes in two vectors, the dependent variable and the independent variable, and outputs a vector of regression coefficients. These coefficients can then be used to fit a line to the data.

There are simple steps to understand how the regression function functions using Matlab, and the procedures are as follows:

  • Step 1. Set up one variable as an explanation or an independent variable, and load the entire input data.
  • Step 2. Add another variable to be a dependent variable and load all data.
  • Step 3. Write the equation, which could incorporate how steep the line is.
  • Step 4. You can then use the MATLAB Regression function using the correct syntax
  • Step 5. Use the MatLab program to generate the output.

Linear and Polynomial Regression

In linear regression, one or more predictor variables are used to predict a continuous outcome variable based on one or more predictor variables. The outcome variable is constant because it can take on any value within a range (e.g., income, height, weight, etc.). Predictors can be continuous or categorical (e.g., age, gender, race, etc.).

Polynomial regression is a generalization of linear regression that allows for predicting a continuous outcome variable based on one or more predictor variables. Unlike linear regression, however, polynomial regression can model nonlinear relationships between the predictor and outcome variables.

Both methods find the best fit line or curve for a set of data points. The main difference between the two is the type of curve fitted to the data. Linear regression produces a straight line, while polynomial regression produces a curved line.

Regression by linear equation is the simplest of the two methods and is usually the first choice when predicting future values. However, if the relationship between the dependent and independent variables is nonlinear, then polynomial regression may be a better choice.

Nonlinear Regression With APM Matlab

APM Matlab is a powerful tool for nonlinear regression analysis. It can fit nonlinear models to data with multiple predictor variables. In this below section, learn how to use APM Matlab for nonlinear regression.

First, you will need to load the data into APM Matlab. To do this, open the data file in APM Matlab and select the "Nonlinear Regression" option from the " Analysis" menu. Next, select the "Predictor Variables" option and choose the predictor variables you want to use in the model. Finally, select the "Dependent Variable" and choose the variable you want to predict.

Once the data is loaded, you will need to specify the type of model that you want to use. APM Matlab offers a variety of different kinds of models, including linear, polynomial, exponential, and logistic models. You can also specify the number of predictor variables you want to use in the model.

After specifying the model type, you will need to estimate the model parameters. Select the "Estimate" button from the " Analysis" menu to do this. APM Matlab will estimate the model parameters using the data you have loaded.

Once the model parameters have been estimated, you can use the " predict" function to predict new values for the dependent variable. To do this, select the "Predict" button from the " Analysis" menu and enter the values of the predictor variables you want to use in the prediction. APM Matlab will then predict the value of the dependent variable for each value of the predictor variables you entered.

Become a Data Scientist With Real-World Experience

Data Scientist Master’s ProgramExplore Program
Become a Data Scientist With Real-World Experience

Examples of Matlab Regression

Let's look at an example that illustrates Matlab regression and see how it functions in Matlab. As we are aware of Matlab's regression procedure, we utilized Matlab's MATLAB Function for Regression. Let's say the number of observations is 100. We then make the artificial noise with the function rand. "noise is randn(n,1);" this line is used to generate an artificial sound. Following that, we generate the independent variable"x. "x=rand(n,1). *10" This line is the source of an independent variable, x, artificially increased over the noise.

Following that, we are ready to create the equation. "y= 2+3.5*x+noise;" this sequence is the equation. Here slope for the independent variable x is 3.5. We also add artificial noise to this equation. We then plot the graph using the plot function between the independent variable x and the dependent variable y. Then, we use the "lsline" syntax to draw an outline and plot it. Following that, we construct the beta values we first created by connecting the ones. Utilizing "X= [ones(size(x)) *x";" This line is used to create the initial beta values, and, finally, we generate the final beta making use of this MATLAB regression function. "beta = regress(y,X)" This given equation generate the beta. After executing the Matlab code, we will get two beta values.



clear all;

close all;

n =100;

noise = randn(n,1);


y= 2+3.5*x+noise;



X= [ones(size(x)) x];

beta = regress(y,X)




1. Can you do regression in Matlab?

Yes, you can do regression in Matlab. Matlab has several built-in functions that make it easy to fit linear and nonlinear models to data. You can also use Matlab to customize your regression algorithms.

2. What is regression analysis in Matlab?

The purpose of regression analysis is to investigate the relationships between different variables. It can predict future events or behaviors, understand how various factors influence each other, or identify trends or patterns.

3. How do you do simple linear regression in Matlab?

There are many ways to do linear regression in Matlab. The simplest way is to use the fitlm function, which will automatically fit a linear model to your data. You can also use the polyfit function to fit a polynomial model to your data. If you want more control over the fitting process, you can use the lsqlin function.

4. What is lm in Matlab?

Matlab's LinearModel class offers a set of functions that make it easy to fit linear models to data. Linear models are a type of mathematical model that can describe a wide variety of physical phenomena. In general, a linear model is any equation that can be written:

y = mx + b

Where y = dependent variable, m=slope of the line, x= independent variable, and b=intercept. The linear model class offers a variety of functions for fitting linear models to data, including functions for estimating the slope and intercept computing predictions and calculating confidence intervals.

5. What is linear regression in MATLAB?

The linear regression method is used to find the linear relationship between two variables. In other words, it helps us to understand how one variable changes in relation to another. Linear regression is a powerful tool used to make predictions and is often used in fields such as engineering, finance, and statistics.

6. How do you predict in MATLAB?

In MATLAB, there are several ways to predict future values. The most common method is to use a linear regression, which is the best fit line for a data set. We can then predict future values. Other methods of prediction include using a polynomial regression or a neural network.


Matlab regression is a powerful tool for analyzing data. It is easy to use and can provide insights that would be difficult to obtain with other methods. This article briefly introduces Matlab regression and how to use it to do data regression. Enroll in the Caltech Data Science Bootcamp to learn more about data regression.
